Atlantic 75
Crew:
Atlantic 75 – 3
Survivor capacity:
20
Maximum speed:
Atlantic 75 – 32 knots
Range / endurance:
Atlantic 75 – 2.5 hours
Length:
Atlantic 75 – 7.383m
Beam / width:
Atlantic 75 – 2.65m
Draught / depth:
Atlantic 75 – 0.41m
Displacement / weight:
Atlantic 75 – 1.6 tonnes
Fuel capacity:
Atlantic 75 – 182 litres
Engines:
Atlantic 75 – 2 x Yamaha 3 cylinder 2-stroke 1.1 litre 75hp outboard petrol engines
Construction:
Atlantic 75
Hull: polyester glass-reinforced fibre, with marine plywood stiffening.
Inflatable collar: hypalon-coated nylon.
Communications and navigation
Includes:
fitted and hand-held VHF (very high frequency) radio
electronic chart.
Freshwater D Class Lifeboat
The Inshore D-Class is the smaller of our two Lifeboats, which often leads the public to think of the larger B-Class as our main Lifeboat. In reality the D-Class is our day to day Lifeboat, and is used by the FILB on more shouts than the larger B-Class due to its versatility and ability to get in close to the shore. The D-Class will generally operate with three crew members on board leaving plenty of room for up to 3 casualties to be brought on board. It has a 50 HP Mariner Outboard motor with two separate fuels tanks, meaning that can reach a top speed of 25 knots. At that speed within 10 minutes of launch we can be at Compton or the Needles. Primary operations for the D-Class are helping casualty vessels in need, performing recoveries from the cliffs, searches for people or animals in distress along the shoreline, and providing safety overwatch from the water. The D-Class enables the FILB to get onto the beaches and into the various caves that are dotted along the coastline.
The D-Class carries onboard:
VHF Radio
GPS Chart Plotter
Towing ropes and springs
4 Throw Ropes
First Aid Kit
Neck and various other braces
Compass
Spare Propellor Blade
Foot pump
Flares
Fire Extinguisher
Rope cutters
Water Bottles
